Power Distribution System
Precision Combined Cabinet Delixi 250A 30-Circuit
Precision Combined Cabinet Delixi 250A 30-Circuit
Package price¥16,988.07
Bill of materials
| Brand | Model | Qty | Price | |
|---|---|---|---|---|
| Domestic high quality | Rack W600*H2000*D1200 | 1 | ¥3,222.00 | |
| Delixi | CDQ3HB-250S/4P 250A whole | 1 | ¥2,268.47 | |
| Delixi | DZ47s C 4P 25A | 1 | ¥13.52 | |
| Delixi | CDM3-250S/3300 250A | 2 | ¥222.87 | |
| Delixi | DZ47s C 3P 63A | 6 | ¥11.74 | |
| Delixi | DZ47s C 2P 63A | 2 | ¥7.93 | |
| Delixi | DZ47s C 2P 32A | 2 | ¥6.76 | |
| Delixi | DZ47s C 1P 32A | 18 | ¥3.22 | |
| Delixi | DZ47s C 1P 16A | 2 | ¥3.22 | |
| Domestic high quality | Padlock lock setting Standby | 1 | ¥30.00 | |
| Schneider | NSX-Interphase Separator (NSX100-250A)1 strings 6 pieces | 2 | ¥56.49 | |
| Acrel | Sub-Circuit Switch Volume AMC16Z-KD | 1 | ¥540.00 | |
| National standard | Copper busbar | 11 | ¥100.00 | |
| Schneider Wanguo | iPRU 20 4P | 1 | ¥1,192.54 | |
| Acrel | 7 inch Touchscreen FE4070CE-A | 1 | ¥1,275.00 | |
| Acrel | Main -Circuit Module AMC16Z-ZA | 1 | ¥293.00 | |
| Acrel | 250/5A | 9 | ¥35.10 | |
| Acrel | Branch-Circuit Module AMC16Z-FA | 2 | ¥460.00 | |
| Acrel | W-12N 60A/20mA | 20 | ¥20.00 | |
| Acrel | W-9N 50A/50mA | 28 | ¥10.00 |
Request a quote
Leave your details and an engineer will get back to you within one business day.
