Power Distribution System
ATS Precision Distribution Cabinet CHINT 100A 4P 25-Circuit (Variant)
ATS Precision Distribution Cabinet CHINT 100A 4P 25-Circuit
Package price¥14,009.40
Bill of materials
| Brand | Model | Qty | Price | |
|---|---|---|---|---|
| Totem | Rack W600*H2000*D1000 | 1 | ¥2,000.00 | |
| CHINT | NH40-100/4SZ | 1 | ¥780.00 | |
| CHINT ELECTRICAL APPLIANCES | NXM-125S/4300B 100A | 1 | ¥203.04 | |
| CHINT ELECTRICAL APPLIANCES | NB1-63 4P C63 6kA(R) | 1 | ¥37.63 | |
| CHINT ELECTRICAL APPLIANCES | NXM-125S/3300 100A | 3 | ¥147.60 | |
 | CHINT ELECTRICAL APPLIANCES | NXB-63 1P C32 | 25 | ¥5.44 |
| Domestic high quality | Interphase separator 1 strings 6 pieces | 4 | ¥50.00 | |
| Domestic high quality | Padlock lock setting Standby | 1 | ¥30.00 | |
| Domestic high quality | AM1-80/4 | 1 | ¥273.00 | |
| Acrel | Touchscreen ATP007 | 1 | ¥600.00 | |
| Acrel | Main -Circuit Module AMC16Z-ZA | 1 | ¥293.00 | |
| Acrel | Branch-Circuit Module AMC16Z-FAK24 | 1 | ¥391.00 | |
 | Acrel | Branch-Circuit Module AMC16Z-FAK48 | 1 | ¥587.00 |
| Domestic high quality | LC 100/5 | 6 | ¥34.88 | |
 | Acrel | W-9N 50A/50mA | 25 | ¥10.00 |
| Acrel | W-20N 100A/50mA | 3 | ¥72.00 | |
| National standard | Copper busbar | 10 | ¥100.00 |
